Abracon公司为美国杰出的知名制造商,一直致力于研究高质量的石英晶体,通过自身的努力终有了一番成绩,为广泛应用程序提供了广泛的石英定时晶体和振荡器,MEMS振荡器,实时时钟(RTC),蓝牙模块,陶瓷谐振器,锯滤器和谐振器,功率和射频电感,变压器,电路保护元件和射频天线和无线充电线圈。艾博康的高质量石英晶体ABM8W-38.4000MHZ-4-B2U-T3,比较适合用于超低功耗MCU
The primary driving force behind this industry trend is related to the reduction in total consumed power, while improving overall performance. This effort is being undertaken to facilitate the practical implementation of battery powered end-solutions (consumer, medical, IoT, industrial, etc.), requiring extremely low power in a feature-rich environment. These advancements, however, have significantly impacted the traditional clocking circuit.
